SPECIFICATIONS:
Class D
400W RMS
4 Channel
RMS POWER at 2 Ohm 12.6V 380W RMS
RMS POWER at 4 Ohm 12.6V 220W RMS
BTL RMS POWER at 4 Ohm 12.6V 190W RMS
RMS POWER at 2 Ohm 14.4V 420W RMS
RMS POWER at 4 Ohm 14.4V 260W RMS
BTL RMS POWER at 4 Ohm 14.4V 215W RMS
Suply Voltage 9.5 – 16V
Frequency Response 10Hz – 20KHz
Lp pass Crossover 40Hz – 2KHz
Signal to Noise Tatio 95dB
Harmonic Distortion 1% THD
Input Sensitivity 0.2V
High level input 6V
Dimensions: 116 × 120 × 50 mm
Weight: 0.7 kg.
